Ovation Rêve E-3 IP stands as an outdoor-capable LED ERS-style lighting fixture, marked by its virtually noiseless operation and IP65 certification. Ideal for studio, theatre, and cinematic contexts, this fixture seamlessly adapts to both indoor and outdoor environments. It is outfitted with the most luminous light engine available, enabling the generation of comprehensive full-spectrum colors and customizable tunable whites. Noteworthy attributes of the Ovation Rêve E-3 IP encompass adaptable PWM, a +/- green tuning capability, simulated red-shift, and impeccably fluid 16-bit dimming curves and speeds, making it the perfect complement to any lighting arrangement, regardless of the setting.
Chauvet Pro Includes:
- Ovation Rêve E-3 IP
- Seetronic Powerkon power cable
- Ovation Metal Gobo Holder
- Soft Focus Filter
Chauvet Pro Features:
- Full-spectrum, high-power LED ERS-style lighting fixture for theatre, film, and production
- Fully IP65 rated for seasonal use indoors or out
- Linear color temperature presets from 2800 K to 8000 K with high CRI and CQS
- Virtual color wheel with color matched to popular gel colors
- +/- Green adjustment and emulated red-shift via DMX or on-board control
- RDM (Remote Device Management) for added flexibility
- Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
- Virtually silent operation for use in studio, film, and theatre applications
- Ultra-smooth 16-bit dimming curves and speeds to complement any lighting scheme.
- Innovative adjustable yoke for mounting in low clearance areas
- Direct power/data connection and control options for the Ovation GR-1 gobo rotator
- USB port for fixture software updates
Chauvet Pro Specifications:
- Required Accessories:
- Lens Tube: 5°, 10°, 14°, 19°, 26°, 36°, 50°, 15°-30°, 25°-50°
- Optical:
- Light Source: 91 LEDs (12 red, 19 green, 3 blue, 9 royal blue, 24 amber, 24 mint) 3.5 to 10 W, (2.4 A), 50,000 hours life expectancy
- Color Temperature (range): 2800 to 8000 K
- Color Temperature (at full): 6,428 K
- CRI: 93.5
- Beam Angle (w/5° lens): 6.7°
- Beam Angle (w/10° lens): 11.1°
- Beam Angle (w/14° lens): 14.2°
- Beam Angle (w/19° lens): 17.6°
- Beam Angle (w/26° lens): 26°
- Beam Angle (w/36° lens): 32.8°
- Beam Angle (w/50° lens): 50°
- Beam Angle (w/15°–30° lens)(Narrow): 14.3°
- Beam Angle (w/15°–30° lens)(Wide): 23.8°
- Beam Angle (w/25°–50° lens)(Narrow): 24.7°
- Beam Angle (w/25°–50° lens)(Wide): 41.1°
- Field Angle (w/5° lens): 7.9°
- Field Angle (w/10° lens): 12.8°
- Field Angle (w/14° lens): 16.9°
- Field Angle (w/19° lens): 20.8°
- Field Angle (w/26° lens): 28.2°
- Field Angle (w/36° lens): 37°
- Field Angle (w/50° lens): 54.2°
- Field Angle (w/15°–30° lens)(Narrow): 17.3°
- Field Angle (w/15°–30° lens)(Wide): 33.2°
- Field Angle (w/25°–50° lens)(Narrow): 27.3°
- Field Angle (w/25°–50° lens)(Wide): 44.7°
- Lumens (w/5° lens): 8,335
- Lumens (w/10° lens): 11,092
- Lumens (w/14° lens): 10,700
- Lumens (w/19° lens): 10,185
- Lumens (w/26° lens): 12,178
- Lumens (w/36° lens): 11,888
- Lumens (w/50° lens): 11,274
- Lumens (w/15°–30° lens)(Narrow): 9,166
- Lumens (w/15°–30° lens)(Wide): 11,395
- Lumens (w/25°–50° lens)(Narrow): 11,810
- Lumens (w/25°–50° lens)(Wide): 14,328
- Illuminance (w/5° lens): 28,740 lux @ 5 m
- Illuminance (w/10° lens): 15,108 lux @ 5 m
- Illuminance (w/14° lens): 8,823 lux @ 5 m
- Illuminance (w/19° lens): 5,377 lux @ 5 m
- Illuminance (w/26° lens): 3,300 lux @ 5 m
- Illuminance (w/36° lens): 1,977 lux @ 5 m
- Illuminance (w/50° lens): 864 lux @ 5 m
- Illuminance (w/15°–30° lens)(Narrow): 7,731 lux @ 5 m
- Illuminance (w/15°–30° lens)(Wide): 2,484 lux @ 5 m
- Illuminance (w/25°–50° lens)(Narrow): 3,174 lux @ 5 m
- Illuminance (w/25°–50° lens)(Wide): 1,502 lux @ 5 m
- Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
- Dynamic Effects:
- Dimmer: Electronic
- Shutter/Strobe: Electronic
- Focus: Manual
- Strobe Rate: 0 to 28.6 Hz
- Standalone Color Mixing: Yes
- Color Temperature Presets: Yes
- Dim Modes: 4
- Dim Curves: 4
- Built-in Automated Programs: Yes
- Construction / Physical:
- Dimensions (fixture only, yoke up): 20.83 x 12.71 x 19.75 in (529.3 x 323 x 501.7 mm)
- Dimensions (w/5° lens extended, yoke up): 42.25 x 14.5 x 19.75 in (1073.15 x 368.3 x 501.7 mm)
- Dimensions (w/10° lens extended, yoke up): 33.5 x 12.71 x 19.75 in (850.9 x 323 x 501.7 mm)
- Dimensions (w/14° lens extended, yoke up): 30.25 x 12.71 x 19.75 in (768.35 x 323 x 501.7 mm)
- Dimensions (w/19°, 26°, 36° or 50° lens extended, yoke up): 27.5 x 12.71 x 19.75 in (698.5X 323 X 501.7 mm)
- Dimensions (w/15°–30° lens, yoke up): 33.75 x 12.71 x 19.75 in (857.25 x 323 x 501.7 mm)
- Dimensions (w/25°–50° lens, yoke up): 26.5 x 12.71 x 19.75 in (673.1x 323 x 501.7 mm)
- Weight: 20.6 lb (9.34 kg)
- Weight (w/5° lens): 25.2 lb (11.43 kg)
- Weight (w/10° lens): 23.8 lb (10.79 kg)
- Weight (w/14° lens): 26 lb (11.79 kg)
- Weight (w/26° lens): 24.4 lb (11.06 kg)
- Weight (w/15°–30° lens): 30.2 lb (13.69 kg)
- Weight (w/25°–50° lens): 26.8 lb ( 12.15 kg)
- Exterior Color: Black
- Housing Material: Magnesium alloy
- Gobo Size (Optional): “A”: 100 mm (outside), 75 mm (image), 2.5 mm (max. thickness)
- Gobo Size (Optional): “B”: 86 mm (outside), 64.5 mm (image), 2.5 mm (max. thickness)
- Accessory Holder/Gel Frame Size (5° lens): 14 in (356 mm)
- Accessory Holder/Gel Frame Size (10° lens): 12 in (304 mm)
- Accessory Holder/Gel Frame Size (14° lens): 7.5 in (191 mm)
- Accessory Holder/Gel Frame Size (19°, 26°, 36°, and 50° lens): 6.25 in (159 mm)
- Accessory Holder/Gel Frame Size (15°–30° lens): 7.5 in (191 mm)
- Accessory Holder/Gel Frame Size (25°–50° lens): 7.5 in (191 mm)
- Connections:
- Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
- Power Input: Seetronic Powerkon IP65
- Power Output: Seetronic Powerkon IP65
- Data Connectors: 5-pin XLR
- Cable Length (power): 5 ft (1.5 m)
- Software Connection: Type-C USB
- Control:
- Control Protocol: DMX, RDM
- DMX Channels: 1, 5, 6, 8, 12, 14ch1, 14ch2, 18 or HSV
- Modes/Personalities: 9 personalities (1, 5, 6, 8, 12, 14ch1, 14ch2, 18, HSV)
- Electrical:
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power Linking: 4 units @ 120 V; 7 units @ 208 V; 7 units @ 230 V
- Power and Current: 354 W, 2.999 A @ 120 V, 60 Hz
- Power and Current: 345 W, 1.707 A @ 208 V, 60 Hz
- Power and Current: 342 W, 1.555 A @ 230 V, 50 Hz
- Certifications / Qualifications:
- CE, MET, FCC, UKCA
- IP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
- Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
